النسخ المتماثل للبيانات

mkdir cluster_1S_2R
cd cluster_1S_2R

# Create clickhouse-keeper directories
for i in {01..03}; do
  mkdir -p fs/volumes/clickhouse-keeper-${i}/etc/clickhouse-keeper
done

# Create clickhouse-server directories
for i in {01..02}; do
  mkdir -p fs/volumes/clickhouse-${i}/etc/clickhouse-server
done

for i in {01..02}; do
  mkdir -p fs/volumes/clickhouse-${i}/etc/clickhouse-server/config.d
  mkdir -p fs/volumes/clickhouse-${i}/etc/clickhouse-server/users.d
  touch fs/volumes/clickhouse-${i}/etc/clickhouse-server/config.d/config.xml
  touch fs/volumes/clickhouse-${i}/etc/clickhouse-server/users.d/users.xml
done

<clickhouse replace="true">
    <logger>
        <level>debug</level>
        <log>/var/log/clickhouse-server/clickhouse-server.log</log>
        <errorlog>/var/log/clickhouse-server/clickhouse-server.err.log</errorlog>
        <size>1000M</size>
        <count>3</count>
    </logger>
    <display_name>cluster_1S_2R node 1</display_name>
    <listen_host>0.0.0.0</listen_host>
    <http_port>8123</http_port>
    <tcp_port>9000</tcp_port>
    <user_directories>
        <users_xml>
            <path>users.xml</path>
        </users_xml>
        <local_directory>
            <path>/var/lib/clickhouse/access/</path>
        </local_directory>
    </user_directories>
    <distributed_ddl>
        <path>/clickhouse/task_queue/ddl</path>
    </distributed_ddl>
    <remote_servers>
        <cluster_1S_2R>
            <shard>
                <internal_replication>true</internal_replication>
                <replica>
                    <host>clickhouse-01</host>
                    <port>9000</port>
                </replica>
                <replica>
                    <host>clickhouse-02</host>
                    <port>9000</port>
                </replica>
            </shard>
        </cluster_1S_2R>
    </remote_servers>
    <zookeeper>
        <node>
            <host>clickhouse-keeper-01</host>
            <port>9181</port>
        </node>
        <node>
            <host>clickhouse-keeper-02</host>
            <port>9181</port>
        </node>
        <node>
            <host>clickhouse-keeper-03</host>
            <port>9181</port>
        </node>
    </zookeeper>
    <macros>
        <shard>01</shard>
        <replica>01</replica>
        <cluster>cluster_1S_2R</cluster>
    </macros>
</clickhouse>

<listen_host>0.0.0.0</listen_host>

<http_port>8123</http_port>

<tcp_port>9000</tcp_port>

<logger>
    <level>debug</level>
    <log>/var/log/clickhouse-server/clickhouse-server.log</log>
    <errorlog>/var/log/clickhouse-server/clickhouse-server.err.log</errorlog>
    <size>1000M</size>
    <count>3</count>
</logger>

<remote_servers>
    <!-- cluster name (should not contain dots) -->
    <cluster_1S_2R>
        <!-- <allow_distributed_ddl_queries>false</allow_distributed_ddl_queries> -->
        <shard>
            <!-- Optional. Whether to write data to just one of the replicas. Default: false (write data to all replicas). -->
            <internal_replication>true</internal_replication>
            <replica>
                <host>clickhouse-01</host>
                <port>9000</port>
            </replica>
            <replica>
                <host>clickhouse-02</host>
                <port>9000</port>
            </replica>
        </shard>
    </cluster_1S_2R>
</remote_servers>

<zookeeper>
    <node>
        <host>clickhouse-keeper-01</host>
        <port>9181</port>
    </node>
    <node>
        <host>clickhouse-keeper-02</host>
        <port>9181</port>
    </node>
    <node>
        <host>clickhouse-keeper-03</host>
        <port>9181</port>
    </node>
</zookeeper>

<macros>
    <shard>01</shard>
    <replica>01</replica>
    <cluster>cluster_1S_2R</cluster>
</macros>

for i in {01..03}; do
  touch fs/volumes/clickhouse-keeper-${i}/etc/clickhouse-keeper/keeper_config.xml
done

<tcp_port>9181</tcp_port>
<server_id>{id}</server_id>

<raft_configuration>
    <server>
        <id>1</id>
        <hostname>clickhouse-keeper-01</hostname>
        <!-- TCP port used for communication between ClickHouse Keeper nodes -->
        <port>9234</port>
    </server>
    <server>
        <id>2</id>
        <hostname>clickhouse-keeper-02</hostname>
        <port>9234</port>
    </server>
    <server>
        <id>3</id>
        <hostname>clickhouse-keeper-03</hostname>
        <port>9234</port>
    </server>
</raft_configuration>

docker-compose up -d

[+] Running 6/6
 ✔ Network cluster_1s_2r_default   Created
 ✔ Container clickhouse-keeper-03  Started
 ✔ Container clickhouse-keeper-02  Started
 ✔ Container clickhouse-keeper-01  Started
 ✔ Container clickhouse-01         Started
 ✔ Container clickhouse-02         Started

# Connect to any node
docker exec -it clickhouse-01 clickhouse-client

cluster_1S_2R node 1 :)

docker exec -it clickhouse-keeper-01  /bin/sh -c 'echo mntr | nc 127.0.0.1 9181'

docker exec -it clickhouse-01 clickhouse-client
docker exec -it clickhouse-02 clickhouse-client

CREATE DATABASE IF NOT EXISTS uk
ON CLUSTER cluster_1S_2R;

SHOW DATABASES;

   ┌─name───────────────┐
1. │ INFORMATION_SCHEMA │
2. │ default            │
3. │ information_schema │
4. │ system             │
5. │ uk                 │
   └────────────────────┘

CREATE TABLE IF NOT EXISTS uk.uk_price_paid_local
ON CLUSTER cluster_1S_2R
(
    price UInt32,
    date Date,
    postcode1 LowCardinality(String),
    postcode2 LowCardinality(String),
    type Enum8('terraced' = 1, 'semi-detached' = 2, 'detached' = 3, 'flat' = 4, 'other' = 0),
    is_new UInt8,
    duration Enum8('freehold' = 1, 'leasehold' = 2, 'unknown' = 0),
    addr1 String,
    addr2 String,
    street LowCardinality(String),
    locality LowCardinality(String),
    town LowCardinality(String),
    district LowCardinality(String),
    county LowCardinality(String)
)
ENGINE = ReplicatedMergeTree
ORDER BY (postcode1, postcode2, addr1, addr2);

INSERT INTO uk.uk_price_paid_local
SELECT
    toUInt32(price_string) AS price,
    parseDateTimeBestEffortUS(time) AS date,
    splitByChar(' ', postcode)[1] AS postcode1,
    splitByChar(' ', postcode)[2] AS postcode2,
    transform(a, ['T', 'S', 'D', 'F', 'O'], ['terraced', 'semi-detached', 'detached', 'flat', 'other']) AS type,
    b = 'Y' AS is_new,
    transform(c, ['F', 'L', 'U'], ['freehold', 'leasehold', 'unknown']) AS duration,
    addr1,
    addr2,
    street,
    locality,
    town,
    district,
    county
FROM url(
    'http://prod1.publicdata.landregistry.gov.uk.s3-website-eu-west-1.amazonaws.com/pp-complete.csv',
    'CSV',
    'uuid_string String,
    price_string String,
    time String,
    postcode String,
    a String,
    b String,
    c String,
    addr1 String,
    addr2 String,
    street String,
    locality String,
    town String,
    district String,
    county String,
    d String,
    e String'
) LIMIT 10000
SETTINGS max_http_get_redirects=10;

-- clickhouse-01
SELECT count(*)
FROM uk.uk_price_paid_local

--   ┌─count()─┐
-- 1.│   10000 │
--   └─────────┘

-- clickhouse-02
SELECT count(*)
FROM uk.uk_price_paid_local

--   ┌─count()─┐
-- 1.│   10000 │
--   └─────────┘

CREATE DATABASE IF NOT EXISTS test ON CLUSTER cluster_1S_2R;
CREATE TABLE test.test_table ON CLUSTER cluster_1S_2R
(
    `id` UInt64,
    `name` String
)
ENGINE = ReplicatedMergeTree
ORDER BY id;

INSERT INTO test.test_table (id, name) VALUES (1, 'Clicky McClickface');

docker stop clickhouse-01

docker-compose ps

INSERT INTO test.test_table (id, name) VALUES (2, 'Alexey Milovidov');
SELECT * FROM test.test_table;

docker start clickhouse-01

TRUNCATE TABLE uk.uk_price_paid_local ON CLUSTER cluster_1S_2R;
INSERT INTO uk.uk_price_paid_local
SELECT
    toUInt32(price_string) AS price,
    parseDateTimeBestEffortUS(time) AS date,
    splitByChar(' ', postcode)[1] AS postcode1,
    splitByChar(' ', postcode)[2] AS postcode2,
    transform(a, ['T', 'S', 'D', 'F', 'O'], ['terraced', 'semi-detached', 'detached', 'flat', 'other']) AS type,
    b = 'Y' AS is_new,
    transform(c, ['F', 'L', 'U'], ['freehold', 'leasehold', 'unknown']) AS duration,
    addr1,
    addr2,
    street,
    locality,
    town,
    district,
    county
FROM url(
    'http://prod1.publicdata.landregistry.gov.uk.s3-website-eu-west-1.amazonaws.com/pp-complete.csv',
    'CSV',
    'uuid_string String,
    price_string String,
    time String,
    postcode String,
    a String,
    b String,
    c String,
    addr1 String,
    addr2 String,
    street String,
    locality String,
    town String,
    district String,
    county String,
    d String,
    e String'
    ) SETTINGS max_http_get_redirects=10;
